Al Fanar Enclosure 400Hx300Wx200D

Applications:

Metal Enclosures (IP66) are designed to accommodate various types of switchgear and control gear assemblies to suit a variety of electrical installations in commercial and light industrial premises. They are designed for outdoor applications up to IP66.

Specications:

• Made of high quality electro-galvanized steel sheet of thickness up to 1.5mm

• Matt-finish polyester powder coated in RAL-7032 light grey colour

• Standard mounting plate made of hot dip galvanized steel sheet of 2mm thickness with holes for strips

• Complies with IEC 60529/62208 standards

• Complies with CE standards

• Degree of protection IP65

Features:

• Earthing studs are provided on both the enclosure and the door.

• CNC machine formed a polyurethane gasket for reliable sealing.

• Corner formed door ensures better weatherproofing and gives aesthetic looks.

• Easily removable hinges, ideal for changing the door opening direction (for certain sizes)

• Special profiled lip for better waterproofing.

• Lock features:

−  Quarter turn cylindrical lock

−  Metal keys and locking mechanism for durability.

−  Key engaged when the lock is open

• A kit containing assembly hardware and instruction manual is provided with the enclosure

Specifications:
