Hager Isolator Switch Disconnector RM 4pole – 100A – SBN490N

SBN490
SBN490
4-pole, 100A Modular Switch
Technical characteristics
Architecture
Neutral position without neutral
Number of poles 4 P
Type of pole 4 P
Main electrical features
Rated operational voltage Ue 400 V
Frequency 50/60 Hz
Rated current 100 A
Voltage
Rated insulation voltage 440 V
Rated impulse withstand voltage 6000 V
Dimensions
Depth of installed product 69 mm
Height of installed product 83 mm
Width of installed product 70 mm
Power
Total power loss under IN 22 W
Endurance
Electrical durability at nominal load in AC22
in operating cycles 2500
Number of mechanical operations 40000
Capacity
Number of modules 4
Installation, mounting
Tightening torque 3,6Nm
Connection
Connection cross-sect. flexible conductor 6 / 35mm²
Connection cross-sect. rigid cable 6 / 50mm²
Type of connection with screw
Standards
Standard text IEC 60947-3
European directive WEEE concerned
Safety
Protection index IP IP20
Use conditions
Operating temperature -20…50 °C
Subject to technical modifications
