| Inlet |
1 × 500A, 400V, L1+L2+L3+N+E, IP67 Powerlock Panel Drain Set |
| Unprotected Outlets |
1 × 500A, 400V, L1+L2+L3+N+E, IP67 Powerlock Panel Source Set |
| Protected Outlets |
3 × 125A, 5P, IP67; 3 × 63A, 5P, IP67; 6 × 32A, 5P, IP44; 6 × 32A, 3P, IP44; 6 × 16A, 3P, IP44 |
| Protection |
1 × 400A, 4P MCCB; 3 × 125A, 4P MCBs; 3 × 63A / 100mA, 4P RCBOs; 6 × 32A / 30mA, 4P RCBOs; 6 × 32A / 30mA, 3P RCBOs; 6 × 16A / 30mA, 3P RCBOs |
| Extras |
LED Indicators; 1 × 12mm Earth Stud; 1 × Multifunction Meter |
| Enclosure |
Stackable Shockproof HDPE Enclosure, IP66; Stainless Steel Crash Frame with Side Wheels and Forklift Pockets |
| Enclosure Dimensions (H × W × D) |
1100 × 600 × 600 mm |
